2. To make the signal connections, attach the positive and negative leads of the signal cable
to the connector.
3. Place the second connection cover over the first cover, and snap it into place.
D.12 Connecting to the power supply
To connect the instrument to the power supply, refer to page 21.
Signal connector
Connection cover
