Waters ACQUITY QDa - Page 46

June 28, 2016, 715003956 Rev. C
Page 46
Figure 3–14: Securing the pumping block
8. Fit the ion block and source components to the instrument (see page 37).
9. Fit the source enclosure to the instrument (see page 30).
Securing screws Pumping block
