Figure D–5: External, source exhaust valve assembly—rear configuration
Note: In the figure, the assembly cover is depicted as transparent, to reveal the tubing
connections.
Figure D–6: External, source exhaust valve assembly—front configuration
Note: In the figure, the assembly cover is depicted as transparent, to reveal the tubing
connections.
API gas
connection
Convoluted liquid
waste tubing
Source exhaust
connection
Exhaust tubing
Blanking
fitting
Unused
source
exhaust
connection
Holding screw
API gas
connection
Convoluted liquid
waste tubing
Unused source
exhaust
connection
Exhaust tubing
Blanking
fitting
Source
exhaust
connection
Holding screw
