3-32 Troubleshooting, Testing, and Maintenance
To resume programming after a warning message, do one of these:
•Press CLEAR.
• Wait briefly until the message disappears.
Operational warning messages
Operational warning messages remind you to enter acceptable values and
review your work.
You must heed all warnings and take the appropriate corrective action. The
table below lists the warning messages displayed on the controller.
Operational warning messages
Message Description
Value Entered is
Out of Range
Programming/isocratic/direct control operation
message: Enter a valid value. This message is
accompanied by an audible alarm.
Enter Table
Number for New
Table
Gradient operation: Appears when using the SAVE
function. The table currently in memory and the table
number you entered display. The table currently in
memory will be replaced with the new table in the
next step. This message is accompanied by an audible
alarm.
Replace with New
Table
1 = Yes 0 = No
Gradient operation: Only appears when using the
SAVE function for the Gradient, Event, and Detector
tables. Shows the table to be deleted. Allows you to
abort the save if the table associated with the number
entered should not be erased.
Rear Panel Stop
Flow Input
Detected
Message can appear anytime following a signal at the
Stop Flow terminal. Suspends system operation until
the source of the signal is removed.
Can’t Save Table
Currently
Executing
Gradient operation: The table number you wanted to
save for a new or modified table is the same as the
one running. Abort the run or wait until finished to
replace it with the modified table. This message is
accompanied by an audible alarm.
