2-16 Installing the System
Stacked IEEE-488 connections in a Waters workstation
IEEE-488 connections in a Waters data network
PrepLC
controller
(as gradient
controller)
717plus
Autosampler
2487
Detector
busLAC/E card (Empower) or GPIB card (MassLynx)
IEEE-488
connector
IEEE-488 cable
Data system
PrepLC
controller
(as gradient
controller)
PrepLC controller
(as gradient controller)
LAC/E
module
Data workstation
717plus
Autosampler
2487 UV
Detector
Thin wire
ethernet cable
IEEE-802.3
ethernet connector
IEEE-488
cable
IEEE-488
connector
