D-1
D Plumbing the IntelliStart Fluidics
System
This appendix provides reference information for replacing the tubing in
the IntelliStart™ Fluidics system.
Warning: To avoid electric shock, do not use stainless steel tubing
or stainless steel finger-tight screws to connect the selector valve
to the source probes; use the PEEK tubing and natural (beige)
colored PEEK finger-tight screws specified on page D-4.
Warning: The IntelliStart Fluidics components can be
contaminated with biohazardous and/or toxic materials.
Always wear chemical-resistant, powder-free gloves while
working on the system.
Contents:
Topic Page
Preventing contamination D-2
The selector valve D-2
Plumbing schematic D-3
Tubing and connection specifications D-3
