Removing and refitting the source enclosure 4-11
Fitting the source enclosure to the instrument
Required material
Chemical-resistant, powder-free gloves
To fit the source enclosure:
1. Using both hands, fit the source enclosure to the two supporting studs
on the source adaptor housing.
2. Close the source enclosure.
3. Connect the probe adjuster and options cables to the instrument’s
connectors.
Warning: The source components can be contaminated with
biohazardous and/or toxic materials. Always wear
chemical-resistant, powder-free gloves while performing this
procedure.
Warning: To avoid puncture wounds, take great care while fitting
the source enclosure to the source if a corona pin is fitted (the pin
tip is sharp).
Caution: For the NanoFlow source, to prevent the sprayer from
colliding with the cone and breaking, always retract the stage
before closing the source enclosure door.
