4-10 Maintenance Procedures
5. Using both hands, grasp the source enclosure and lift it vertically off the
two supporting studs on the source adaptor housing.
6. Store the cables neatly by plugging them into the cable-storage positions
on the rear of the source enclosure.
TP03164
Supporting stud
Source enclosure
Cable storage positions
