qdos 30:

ReNu pumphead

(left hand mounted)

Pumphead retaining

clamps

Outlet

Inlet

Power

Mounting plate

HMI

(not Remote)

Drive unit

qdos 30 with 110v or 24v relay module:

pumphead retaining

clamps

ReNu pumphead

(left hand mounted)

Outlet

Inlet

Power

Mounting plate

110V or 24V relay

module

HMI

(not Remote)

Drive unit

m-qdos-en-02 14
