6 Pump specifications

qdos 20, 60 and 120:

ReNu pumphead

(left hand mounted)

Pumphead locking

latch

Outlet

Inlet

Mounting plate

HMI

(not Remote)

Drive unit

qdos 20, 60 and 120 with relay module:

ReNu pumphead

(left hand mounted)

Pumphead locking

latch

Outlet

Inlet

Mounting plate

110v or 24v relay

module

HMI

(not Remote)

Drive unit

m-qdos-en-02 13
