Choose REJECT to return to the language choice screen.
The pump is preset with operational parameters as shown in the table below:
First-time start-up defaults
Flow rate
qdos120:960ml/min
qdos60:480ml/min
qdos30:240ml/min
qdos20:120ml/min
Pump status Stopped
Calibration
qdos120:16 ml/rev
qdos60:6.67ml/rev
qdos30:8 ml/rev
qdos20:4 ml/rev
Flow unit ml/min
Backlight 30 minutes Pump tag WATSON-MARLOW
Auto restart Off
This then proceeds to the home screen.
