Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
24
Audi A1
Cutting per-
forated
bracket to
length
Petrol and 1.4 TDI
Insert cable tie 4 between perforated
bracket
2 and body.
1 Premount M6x25 bolt, pin lock
3 M6x20 bolt, flanged nut, original vehi-
cle hole
Installing
perforated
bracket
Attach metering pump mount 1 with a sup-
port angle bracket and a flanged nut to the
M6x25 bolt. Close cable tie
3 around me-
tering pump mount
1 .
2 Metering pump
Installing
metering
pump
Completing
metering
pump connec-
tor
62
64
65
1 2
34
66
1
3
2
Pin assignment is not relevant.
Connector X7
67
