Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
39
Audi A1
1 Cable tie
2 Heat exchanger inlet hose section
Connect-
ing heat ex-
changer
inlet
1 Heat exchanger inlet hose section
Routing in
engine
compart-
ment
1 Cable tie [2x]
Routing in
engine
compart-
ment
1
Black (sw) rubber isolator
2 90° connecting pipe of hose D
Connect-
ing engine
outlet
119
1
2
120
E
1
121
1
E
1 E
122
2
E
1
