Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
45
Audi A1
1 Wiring harness bracket
Removing
wiring har-
ness brack-
et
1 Plate nut on original vehicle stud bolt
2 Perforated bracket D
Installing
perforated
bracket
1 Drill out hole to 8.5 mm dia.
Drilling out
hole in an-
gle bracket
1
Counter-
sinking
hole in an-
gle bracket
2
137
1
138
1
2
139
1
90°
11
140
