Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
46
Audi A1
1 Pin lock
2 M6x25 countersunk head screw
Preparing
angle
bracket 2
1 M8x20 bolt, spring lockwasher, in
original vehicle thread
2 Position angle bracket 1 (see next fig-
ure)
Installing
angle
bracket 2
1 Original vehicle nut
Installing
angle
bracket 1
Connect-
ing hose C
141
2 1
142
1
2
143
1
144
C
