Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
55
Audi A1
1 Cable ties
Connecting
heater
1 Cable tie [2x]
2 Perforated bracket E
3 Perforated bracket D
Routing
1 Position black (sw) rubber isolator
2 Attach original vehicle wiring harness
using a cable tie
3 Tighten cable tie
Routing
1
Heat exchanger inlet hose section
Connecting
heat ex-
changer in-
let
172
F
E
B
A G
173
1
2A
G
3
1
174
1
2
G
A
1
3
175
G
1
