Webasto thermo top evo

Ident. No.: 1325133C_EN Status: 09.06.2017 © Webasto Thermo & Comfort SE
44
VW Golf VII / Golf VII Sportsvan / Passat and Skoda Superb
1 Engine outlet hose section
2 Heat exchanger inlet hose section
X =
Cutting
point
1
Heat exchanger inlet hose section
Connect-
ing heat ex-
changer
inlet
1
Engine outlet hose section
2 Position black (sw) rubber profile
Connect-
ing engine
outlet
All vehicles
Slide one 600mm long heat protection
hose each onto hoses
A and F.
1 Twistable spacer bracket [2x]
2 Hose of heat exchanger outlet
Routing on
firewall
126
2
90
X
1
140
127
1
F
128
1
A
2
129
A
1
1F
2
