14
No.
part name
function description
ALARM IN: External sensor input port
9
AUDIO OUT/AUDIO IN
AUDIO IN : Audio input connection terminal
AUDIO OUT : Speaker output terminal
10
Ground Connection
Connection terminals that connects NVR to an outside device
11
Power Input
AC100V~AC240V power cord socket. If power cord is not connected to an grounded
outlet, it may cause damage or malfunction of the product.
