Automatic Voltage Regulator – AVR-A-OPT-06 l 13
4.1 NOMENCLATURE FOR REGULATORS
AVR-A-OPT-06 10A AM/220M E10 D PAR/1
PAR/1: Transformer ratio 1A.
PAR/5: Transformer ratio 5A.
D: Digital input.
E10: Analog input 0 to 10 Vdc.
E9: Analog input +- 9Vdc.
M: Single Phase, T: Three Phase, O: Optional.
Rated supply voltage.
M: Single Phase, T: Three Phase, O: Optional.
Sensing Class
A = 160 to 300V or 320 to 600V.
E = 180 to 240V or 520 to 640V.
G = 85 to 140V or 170 to 280V.
Nominal field current.
Factory defined sequence.
Voltage Regulators.

WEG AVR-A-OPT-06 Specifications

General

Brand	WEG
Model	AVR-A-OPT-06
Category	Controller
Language	English
