Automatic Voltage Regulator – AVR-A-OPT-06 l 25
14 TURNING OFF
With the U/F protection properly configured, turning off the alternator is done by turning off the primary mover.
15 REFERENCE OF THE PRINTED SYMBOLS
Below is the cross reference between the old and the new printed symbols adopted from the serial number: 143106.
E
3/4
3F-F+S2 E1 E2 A+ A- DW CM UP
OLD
E
3/4
3F-F+2 E1 E2 7 6 A B DW C UP
NEW
OLD
NEW
OLD
NEW
