Automatic Voltage Regulator – AVR-A-OPT-06 l 17
5 PROTECTION FUSE
The fuse is used to limit the input current supply in order to extinguish the current in case of failure, avoiding major
problems. The AVR-A-OPT-06 regulator possesses a rectifier that controls the field voltage of the alternator. For the
maximum field voltage, the supplied current at input “3” is half of the field current, and the maximum current of the fuse
should be a little more than half of the current supplied by the regulator. Listed below are some of the fuse
characteristics:
Recommended manufacturer: LittelFuse
Characteristics: Fast action fuse.
Dimensions: 5x20 mm.
Current/Voltage: 3A/250V for 5A model or 5A/250V for 7A model (Table 4.1).
Time for opening (to blow):
Table 5.1: Fuse opening time
Fuse opening time
% of maximum current
Opening time
110% 4 hours (minimum)
135% Max. 1 hour
200% Max. 1 second
6 STANDARDS
The AVR-A-OPT-06 voltage regulators comply with the following international standards:
Table 6.1: Standards
Standard Level
Performance
Criteria
IEC 61000-4-5 – Surge immunity test Asymmetrical: 4kV Symmetrical: 4kV B
IEC 61000-4-4 - Electrical fast transient/burst immunity
test
5Khz repetitions, +/- 2kV peak voltage B
IEC 61000-4-3 – Radiated, radio-frequency,
electromagnetic field immunity test
10V/m field for a frequency range from 80MHz to 1GHz. A
10% maximum variation is allowed at the output voltage for a
radiated frequency between 160MHz and 280MHz. For all
other frequencies the equipment doesn’t present variations
A
IEC 61000-4-2 - Electrostatic discharge immunity test
Contact: 4kV load;
Through the air: 8kV load.
B
IEC 61000-4-11 - Voltage dips, short interruptions and
voltage variations immunity tests
Dip f 30db to 95db dips C and B
IEC 61000-4-6 - Immunity to conducted disturbances,
induced by radio-frequency fields
10V amplitude, 150kHz to 80Mhz A
