Wega Atlas User Manual

espresso coffee machine - electrical diagrams
R
ELE
17
English
6.08 Electrical diagram code WY18090030-WY18090031 *GICAR*
EVT EVC EV3 MP EV2
CV1
CT
F1
JP4 J
P6
JP7
JP5 JP2 JP1
JP8
EV1
TR
-
+
O
CV2 CV3
+
O
-
+
O
-
JP8
CAL
SL
B
L
MA NE MA MA NE
BI RO
GV
VE VE BL VE V
E
RO
BI RO
CN3
CN4
CN5
CN7
CN2
CN6
VE
JP1 JP2 JP3 JP4 JP5 JP6 JP7 JP8
Not managed
Pre-infusion enabled
Dose programming enabled
Boiler filling with pump
Tea key enabled
Tea delivery with pump
Not managed Not managed
Not managed
Pre-infusion disabled
Dose programming disabled
Boiler filling without pump
Tea key disabled
Tea delivery without pump
Not managed Not managed
JUMPER INSERTED JUMPER NOT INSERTED
CAL Boiler CT Power supply connector CV1 Volumetric counter GR1 CV2 Volumetric counter GR2 CV3 Volumetric counter GR3 EV1 Solenoid valve GR1 EV2 Solenoid valve GR2 EV3 Solenoid valve GR3 EVC Boiler filling solenoid valve EVT Tea solenoid valve
F1 Inlets fuse (500mA) MP Pump CN2 Power supply CN3 Push button panel connector GR1 CN4 Push button panel connector GR2 CN5 Push button panel connector GR3 CN6 Service outputs connector CN7 Low voltage power supply SL Boiler level probe TR Transformer
BI White BL Blue GV Yellow-green MA Brown NE Black RO Red VE Green

Wega Atlas Specifications

General

Boiler Material	Copper
Water Level Indicator	Yes
Type	Espresso Machine
Material	Stainless Steel
Frequency	50/60 Hz
