10. PROCEDURE IN CASE OF POWER FAILURE
If there is a power outage, the system will store all data concerning the count of servings delivered.
Since the update of the count takes place at the start of the delivery of the serving, if it is aborted due to a power outage, it is still counted
and recognized by the dosing device. In this case, delivery is not performed and the serving is not counted.
11. TECHNICAL DATA
GENERAL DATA
• Power supply voltage 200-230Vac or 100-115Vac
• Operating temperature 10-55°C
• Operating humidity 30-85 % RH without condensation
• Transformer 2 VA - clim.categ. T70/E - 4 KVca
• Input - keys Switch / Pure contact
• Signals for serial transmission RS232 0-5V
CONNECTIONS for “PANEL” model
• Power supply FAST - ON
• Analogue inputs Included for AMPMODU2
• Digital inputs AMPMODU2
• High voltage outputs Included for FAST-ON
• Serial connection AMPMODU2
CONNECTIONS for “COUNTERTOP” model
• Power supply Bi-polar plug
• Digital inputs Cable with activation keys inside the case
• Serial connection 5-way circular connection
12. INSTRUCTIONS FOR INSTALLATION AND LIMITATIONS OF USE
WIRING
Wiring of the cards must be laid out in consideration of the need to separate low voltage from high voltage connections.
The length of any cable must be as short as possible to allow correct connection.
If necessary, screened cables must be used.
The unit must also be located far from devices which may create electromagnetic disturbances when in operation, such as pumps, solenoid
valves, remote switches, motors in general, and neon lights.
SURROUNDINGS
The unit must be placed as far as possible from potential heat sources and excessive humidity and from places where, for any reason, con-
densation may form.
SOILING
Inside the machine, the card must be suitably protected against soiling.
By definition, “in general, the inside of a unit having a case which sufficiently protects it from dust is considered to be protected against soiling”
(EN 60335-1).
