Wega Atlas User Manual

English
CNS
7
espresso coffee machine -
interface system
R
1.5 NOVA type machine electrical diagram version *GIEMME*
A
Hartwall cable 8.9.28.51 code WY22550
REF. DESCRIPTION
B
White
C
Power cable 8.9.28.12 code WY22551
D
Serial transmission cable 8.9.28.13 code WY22552
E
Dosing
F
Short circuit JP1
G
Never place the lever in the PROG position
I
Interface
N
Black
R
Red
V
Green
A
I
C
D
E
F
G
R
B
V
R
N
R
B
V
R (VCC+)
N (GND)
