Wega Atlas User Manual

espresso coffee machine - electrical diagrams
R
ELE
21
English
CN1 Power supply connector CN2 Low voltage power supply CN3 Display connector CN4 Serial transmission connector CN5 Microprocessor connector CN10 Push button panel connector GR1 CN11 Push button panel connector GR2 CN12 Push button panel connector GR3 CN13 Push button panel connector GR4 CN14 Service outputs connector CN17 Connector boiler NTC CN18 Connector Cup heater NTC CN19 Connector Cup heater heating el. CT Power supply connector CAL Boiler IC1 Microprocessor MP Pump TLR Remote switch TRF1 Transformer TAZZ Cup heater BI White BL Blue GV Yellow-green MA Brown NE Black RO Red VE Green
CV1 Volumetric counter GR1 CV2 Volumetric counter GR2 CV3 Volumetric counter GR3 CV4 Volumetric counter GR4 EV1 Solenoid valve GR1 EV2 Solenoid valve GR2 EV3 Solenoid valve GR3 EV4 Solenoid valve GR4 EVC Filling solenoid valve Boiler EVT Tea solenoid valve F1 Ouputs fuse (6,3A) F2 Inputs fuse (500mA) RL1 Solenoid valve relay Pump RL2 Solenoid valve relay GR2 RL3 Solenoid valve relay GR3 RL4 Solenoid valve relay Boiler RL5 Solenoid valve relay GR4 RL6 Solenoid valve relay GR1 RL8 Boiler heating element relay RL9 Solenoid valve relay Tea RL5-2
Solenoid valve relay cup heater
JP1 JP2 JP3 JP4 JP5 JP6 JP7 JP8 JP9
JP10 JP12 JP14 JP15 JP16 JP17 JP18
Serial transmission Pre-infusion Programming Boiler filling Tea delivery Tea STOP key continuation Not managed Credit-Debt Not managed Not managed Not managed Display function keys Device Not managed Not managed
Enabled Enabled
With pump With pump
Disabled
Enabled Enabled
6-key dosing
INSERTED
NOT
INSERTED
Disabled Disabled
Without pump Without pump
Enabled
Disabled Disabled
4-key dosing
(*)
JP12 JP14
JP12 JP14
CREDIT-DEBT INTERFACE I/O
Configuration JP12- JP14
For version whitout DISPLAY: not managed
JP15(*)

Wega Atlas Specifications

General

Boiler Material	Copper
Water Level Indicator	Yes
Type	Espresso Machine
Material	Stainless Steel
Frequency	50/60 Hz
