INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 5-2 SECTION 5: APPENDICES
Figure AFigure A-- 1: Mask of the E1 Pulse (CEPT1: Mask of the E1 Pulse (CEPT-- 11)
219
10%
10%
10%
10%
10%
10%
269
(244 + 25)
194 ns
(244 – 50)
244 ns
20%
488 ns
(244 + 244)
20%
20%
V=100%
50%
0%
Nominal pulse
CCITT-32540
Note –
V corresponds to the nominal peak
