INSTALLATION AND MAINTENANCE MANUAL
E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
SECTION 5: APPENDICES PAGE 5-11
Shaded switch positions are factory default
1 2 3 4 5 6 7 8
SW1 1 NotUsed NotUsed
0 0 0 0 0 0 0 0 0
1 2 Loss of Input Data Alarm (2xE1)
0 0 Enable
1 1 Disable
3 4 Loss of Input Data Alarm ($xE1)
0 0 Enable
1 1 Disable
Diagnostics Port 7
TBOS 0
Craft / SNMP Proxy 1
Aux Data Port 8
Bridged (TBOS) 0
Enabled (Clear) 1
1 2 3 4
SW2 1
0 0 0 0 0
2xE1 & 4xE1 4xE1
1 2 3 4 CEPT-1 Ground
0 0 0 0 Floating
1 1 1 1 Grounded
1 2 3 4 5 6 7 8
SW3 1 NotUsed x x x x
0 0 0 0 0 x x x x
1 Loopback Test Source
0 Internal
1 External
2 Error LED Latch
0 Enable
1 Disable (Flash)
3 Rx AIS Output
0 Enable
1 Disable
Frequency 5 6 7 8
A1 0 0 0 0
A2 0 0 0 1
B1 0 0 1 0
B2 0 0 1 1
C1 0 1 0 0
C2 0 1 0 1
D1 0 1 1 0
D2 0 1 1 1
E1 1 0 0 0
E2 1 0 0 1
F1 1 0 1 0
F2 1 0 1 1
G1 1 1 0 0
G2 1 1 0 1
Table BTable B-- 8 Lynx 2xE1, 4xE1 1.5 GHz Switch Settings8 Lynx 2xE1, 4xE1 1.5 GHz Switch Settings
