INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 5-8 SECTION 5: APPENDICES
Shaded switch positions are factory default
1 2 3 4 5 6 7 8
SW1 1
0 0 0 0 0 0 0 0 0
1 2 Loss of Input Data Alarm
0 0 Enable
1 1 Disable
3 Loopback Test Source
0 Internal
1 External
4 Error LED Latch
0 Enable
1 Disable (Flash)
5 Rx AIS Output
0 Enable
1 Disable
Diagnostics Port 7
TBOS 0
Craft / SNMP Proxy 1
Aux Data Port 8
Bridged (TBOS) 0
Enabled (Clear) 1
1 2 3 4
SW2 1
0 0 0 0 0
1 2 3 4 CEPT-1 Ground
0 0 0 0 Floating
1 1 1 1 Grounded
1 2 3 4 5 6 7 8
SW3 1 x x x
0 0 0 0 0 0 x x x
1 2 Not Used
3 4 Loss of Input Data Alarm
0 0 Enable
1 1 Disable
Frequency Xmtr Rcvr 5 6 7 8
A1 2408 2449 0 0 0 0
A2 2449 2408 0 0 0 1
B1 2426 2467 0 1 0 0
B2 2467 2426 0 1 0 1
Table BTable B-- 5: Lynx.HD 4xE1, 2.4 GHz Switch Settings5: Lynx.HD 4xE1, 2.4 GHz Switch Settings
