INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 2-4 SECTION 2: PRODUCT DESCRIPTION
2.2.3 Receiver
All Models
Nominal Receive Level -30 to -60 dBm
Maximum Receive Level -10 dBm error free, +0 dBm no damage
Frequency Selection Rear Panel DIP switches, 7-cavity RF filter assembly
Processing Gain (DSSS) 10 dB minimum (Spread Spectrum models only)
2.4 GHz 1 x E1 2.4 GHz 4 x E1 5.8 GHz 1 x E1
Threshold Rx Level -93 dBm -88 dBm -92 dBm
(BER = 10
-6
)
Frequency Range 2400 - 2400 - 5725 -
2483.5 MHz 2483.5 MHz 5850 MHz
System Gain 123 dB 118 dB 122 dB
5.8 GHz 2 x E1 5.8 GHz 4 x E1 5.8 GHz 8 x E1
Threshold Rx Level -90 dBm -88 dBm -83 dBm
(BER = 10
-
6
)
Frequency Range 5725 - 5725 - 5725 -
5850 MHz 5850 MHz 5850 MHz
System Gain 120 dB 118 dB 113 dB
1.5 GHz 2 x E1 1.5 GHz 4 x E1 (future–consultfactory
Threshold Rx Level -91 dBm -88 dBm
(BER = 10
-6
)
Frequency Range 1427 - 1427 -
1518 MHz 1518 MHz
System Gain 121 dB 118 dB
