INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 2-6 SECTION 2: PRODUCT DESCRIPTION
System (Single Hop Performance)
Transmit Frequencies
2.4 GHz 1xE1 5.8 GHz 1xE1 5.8 GHz 2xE1 5.8 GHz 4xE1 2.4 GHz 4xE1
sc (31500) sc (31400) sc (31700) (31850) HD (31350)
A1 channel 2410 MHz 5735 MHz 5741 MHz 5735 MHz 2408 MHz
A2 channel 2453 MHz 5800 MHz 5803 MHz 5800 MHz 2449 MHz
B1 channel 2430 MHz 5755 MHz 5772 MHz 5755 MHz 2426 MHz
B2 channel 2473 MHz 5820 MHz 5834 MHz 5820 MHz 2467 MHz
C1 channel N/A 5775 MHz N/A 5775 MHz N/A
C2 channel N/A 5840 MHz N/A 5840 MHz N/A
5.8 GHz 8xE1
HD (27705-20)
A1 channel 5750 MHz
A2 channel 5825 MHz
Receive Frequencies
2.4 GHz 1xE1 5.8 GHz 1xE1 5.8 GHz 2xE1 5.8 GHz 4xE1 2.4 GHz 4xE1
sc (31500) sc (31400) sc (31700) (31850-20/30) HD (27705-20)
A1 channel 2453 MHz 5800 MHz 5803 MHz 5800 MHz 2449 MHz
A2 channel 2410 MHz 5735 MHz 5741 MHz 5735 MHz 2408 MHz
B1 channel 2473 MHz 5820 MHz 5834 MHz 5820 MHz 2467 MHz
B2 channel 2430 MHz 5755 MHz 5772 MHz 5755 MHz 2426 MHz
C1 channel N/A 5840 MHz N/A 5840 MHz N/A
C2 channel N/A 5775 MHz N/A 5775 MHz N/A
5.8 GHz 8xE1
HD (27705-20)
A1 channel 5825 MHz
A2 channel 5750 MHz
