INSTALLATION AND MAINTENANCE MANUAL
E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
SECTION 2: PRODUCT DESCRIPTION PAGE 2-7
System (Single Hop Performance)
Transmit Frequencies
1.5 GHz 2xE1 1.5 GHz 4xE1
A1 channel 1429.0 MHz TBD MHz
A2 channel 1494.0 MHz TBD MHz
B1 channel 1432.5 MHz TBD MHz
B2 channel 1498.0 MHz TBD MHz
C1 channel 1436.0 MHz TBD MHz
C2 channel 1501.5 MHz TBD MHz
D1 channel 1439.5 MHz TBD MHz
D2 channel 1505.0 MHz TBD MHz
E1 channel 1443.0 MHz TBD MHz
E2 channel 1508.5 MHz TBD MHz
F1 channel 1446.5 MHz TBD MHz
F2 channel 1512.0 MHz TBD MHz
G1 channel 1450.0 MHz TBD MHz
G2 channel 1515.5 MHz TBD MHz
Receive Frequencies
1.5 GHz 2xE1 1.5 GHz 4xE1
A1 channel 1494.0 MHz TBD MHz
A2 channel 1429.0 MHz TBD MHz
B1 channel 1498.0 MHz TBD MHz
B2 channel 1432.5 MHz TBD MHz
C1 channel 1501.5 MHz TBD MHz
C2 channel 1436.0 MHz TBD MHz
D1 channel 1505.0 MHz TBD MHz
D2 channel 1439.5 MHz TBD MHz
E1 channel 1508.5 MHz TBD MHz
E2 channel 1443.0 MHz TBD MHz
F1 channel 1512.0 MHz TBD MHz
F2 channel 1446.5 MHz TBD MHz
G1 channel 1515.5 MHz TBD MHz
G2 channel 1450.0 MHz TBD MHz
