INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 2-8 SECTION 2: PRODUCT DESCRIPTION
2.2.5 Digital Line Interface
All Models
Data Rate 2.048 Mbps
Digital Interface * CEPT-1
Connector BNC female unbalanced, 75 ohm - 1xE1, 2xE1, 4xE1 models only
(optional 120 ohm balanced balun available)
OR RJ45/8 balanced, 120 ohm Pins:1=TT, 2=TR, 4=RT & 5=RR
(optional 75 ohm, unbalanced balun available)
Blue Code ** Alarm Indication Signal (AIS)
Remote Loopback Internal or external test signal (rear panel DIP switch selectable)
* Meets ITU-T G.703.
** Signal is selectable (on/off) and is generated only on data loss or link failure when selected.
2.4 GHz 1xE1 2.4 GHz 2xE1 2.4 GHz 4xE1
Digital Capacity 1 x E1 2 x E1 4 x E1
5.8 GHz 1xE1 5.8 GHz 2xE1 5.8 GHz 4xE1 5.8 GHz 8xE1
Digital Capacity 1 x E1 2 x E1 4 x E1 8 x E1
1.5 GHz 2xE1 1.5 GHz 4xE1
Digital Capacity 2 x E1 4 x E1
