INSTALLATION AND MAINTENANCE MANUAL
E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
SECTION 5: APPENDICES PAGE 5-7
Shaded switch positions are factory default
1 2 3 4 5 6 7 8
SW1 1
0 0 0 0 0 0 0 0 0
1 2 Loss of Input Data Alarm
0 0 Enable
1 1 Disable
3 Loopback Test Source
0 Internal
1 External
4 Error LED Latch
0 Enable
1 Disable (Flash)
5 Rx AIS Output
0 Enable
1 Disable
Diagnostics Port 7
TBOS 0
Craft 1
Aux Data Port 8
Bridged (TBOS) 0
Enabled (Clear) 1
1 2 3 4
SW2 1
0 0 0 0 0
1 2 CEPT-1 Ground
0 0 Floating
1 1 Grounded
1 2 3 4 5 6 7 8
SW3 1 x x
0 0 0 0 0 0 0 x x
1 2 Spreading Code
0 0 Code 1
0 1 Code 2
1 0 Code 3
1 1 Code 4
Frequency
Xmtr Rcvr 7 8
A1 5741 5803 0 0
A2 5803 5741 0 1
B1 5772 5834 1 0
B2 5834 5772 1 1
Table BTable B-- 4: Lynx.sc 2xE1, 5.8 GHz Switch Settings4: Lynx.sc 2xE1, 5.8 GHz Switch Settings
