INSTALLATION AND MAINTENANCE MANUAL
E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
SECTION 2: PRODUCT DESCRIPTION PAGE 2-25
switches does not improve immunity to interference. (See Section 3.12 for details)
Interface
Connec-
tion
These switch segments allow the user to have the shield of each CEPT-1 input
connection either grounded or floating. The shield is normally “floating” to eliminate
ground loop problems. (see Section 3.11)
Spread-
ing Code
(Lynx.sc
ONLY !)
This set of switch segments allow the user to select the spreading code for the spread
spectrum signal. Both ends of a radio system must be set to the same code. Users
may wish to change codes for radios that are nearby other similar radios to aid in
interference rejection. (see Section 3.12.3)
This function is not available on the Lynx.HD SS or 1.5 GHz Licensed radios.
Channel
Selection
This set of switch segments programs the radio to match the specific RF channel
corresponding to the RF filter set which has been installed. (see Section 3.12.1)
Address There are two rotary switches which determine the radio's address (01 to 99). This
address is used for Orderwire signaling and for the DIAGNOSTICS port TBOS
address. (see Section 3.14.1)
Refer to Appendix B for Switch Settings
