INSTALLATION AND MAINTENANCE MANUAL
E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
SECTION 2: PRODUCT DESCRIPTION PAGE 3-45
Figure 3Figure 3-- 7: Negative Voltage DC Connection7: Negative Voltage DC Connection
Figure 3Figure 3-- 8: Positive Voltage DC Connection8: Positive Voltage DC Connection
Make sure that when connecting the mating plug that it is properly
oriented (terminal screws pointing up) and securely fastened.
