INSTALLATION AND MAINTENANCE MANUAL
LYNX E1 FAMILY
LICENSED & SPREAD SPECTRUM RADIOS
JUNE 2001
PAGE 3-52 SECTION 3: INSTALLATION & ADJUSTMENTS
RSL (dBm) RSL Voltage (Volts) RSL (dBm) RSL Voltage (Volts)
-25 0.350 -60 0.625
-30 0.359 -65 0.675
-35 0.383 -70 0.725
-40 0.429 -75 0.778
-45 0.479 -80 0.825
-50 0.525 -85 0.858
-55 0.575 -90 0.875
Figure 3Figure 3-- 10B: Typical RSL Voltage vs Receive Signal Level (RSL) for 8xE110B: Typical RSL Voltage vs Receive Signal Level (RSL) for 8xE1
