2.3
SECTION 21 – BODYWORK TRIMMING AND FITTING
Parts Required: -
- Full Set of Bodywork / Water Radiator / Oil Cooler / Cooling Fan / Oil Cooler Brackets / Splitter
Frame and Board / Brake Ducting / Light Fittings Front And Rear / Rear Bodywork Stays / Nose
Fitting Catches And Pins / Windscreen / Side Repeaters
Step 1: Bodywork Trimming
Most of the trimming of your bodywork should have been done for you before you receive it. It is
most important that you pre-fit the bodywork to the chassis before you have it painted.
Check all these areas shown below before the pre-fit.
1.a. Seat Belt Slots
Seat Belt
1.b. Light Holes Front and Rear
Holes to suit
rear light
units
Holes to suit
front light
unit’s
indicator
and side
Mounting
holes for dip
and main
beam
headlamp
brackets
