2.4
1.c. Fog light holes
1.d. Fuel Filler Hole
The main hole will already be in place on your bodywork but you need to drill the six fixing
holes as shown.
Centre Hole For Cable Two
Smaller holes for M5 Retaining
Studs.
Insert filler cap into pre-
cut hole and drill the six
5mm holes through.
1.e. Inner Rear Arches
These Rear arches will be
Pre-trimmed but just check
your clearance when you
have the bodywork on the
rolling chassis doing the Pre-
