2.5
1.f. Windscreen Mounting Holes
Carefully position the windscreen
onto the pre-formed recess, and
drill through the five holes in the
screen with a 4mm drill. Then
remove the screen and drill
through the underside surface
only with a 9mm drill. This is to
allow the M4 nut to clamp up on
the correct face of the bodywork.
1.g. Oil Cooler Mounting
Oil cooler in position mounted
from two brackets supplied
and bolted through the flanges
front and rear of the right
hand side air intake. Mounted
using M6 nuts and bolts.
View from Inside Bodywork Looking At Right Hand Side of Car
