2.10
1.n. Side Repeaters
1.o. Mirror Mounting Holes
Drill a pilot hole in each side of
the bodywork at 380mm from
the bottom of the body and
90mm from the nose location
step. Then file out the shape
shown until it locates the side
repeater correctly.
90mm
380mm
300mm
125mm
Drill one 8mm hole each side
where shown for the mirror
