4.11
MAIN WIRING LOOM DETAILS
CONNECTION LOOM CONNECTOR TYPE LOOM WIRE COLOURS NOTES
LOOM FRONT SECTION
BRAKE LEVEL WARNING LIGHT 4 FEMALE SPADE CONNECTORS BLACK ; BLACK / WHITE 2 PAIRS TOTAL. 1 PAIR TO EACH CYLINDER TOP.
ORIENTATION OF EACH PAIR UNIMPORTANT
BRAKE LIGHT SWITCH 2 FEMALE SPADE CONNECTORS GREEN ; GREEN / PURPLE CONNECTION ORIENTATION UNIMPORTANT
CLUTCH SWITCH CONNECTOR BLOCK WHITE / RED PRE-WIRED - CUSTOMER TO FIT SPARE BLOCK
SUPPLIED TO CLUTCH SWITCH WIRES – BLUE &
BLACK. ORIENTATION UNIMPORTANT
HANDBRAKE WARNING LIGHT BARE WIRES BLACK ; BLACK / WHITE CUSTOMER TO FIT CONNECTION BLOCK SUPPLIED TO
HANDBRAKE SWITCH WIRES – GREY & BLACK.
ORIENTATION UNIMPORTANT
NOSE LOOM 11 WIRE CONNECTOR BLOCK VARIOUS PRE-WIRED
HORN 2 FEMALE SPADE CONNECTORS BLACK ; BLACK TO ONE CONNECTOR
PURPLE / BLACK TO OTHER CONNECTOR
ORIENTATION UNIMPORTANT
NEAR SIDE INDICATOR CONNECTOR BLOCK BLACK ; GREEN / RED PRE-WIRED
FUSE BOX 2 FUSE HOLDER BLOCKS VARIOUS PRE-WIRED BUT TO BE LABELLED, REMOVED &
REFITTED BY CUSTOMER
AUAILIARY PLUG 4 WIRE CONNECTOR BLOCK ORANGE, GREEN, BROWN, BLACK FOR EXTRA AUXILIARY CIRCUIT,
IE; CIGAR LIGHTER ETC
MAIN LOOM POSITVE SUPPLY RING TERMINAL BROWN CONNECTS TO MASTER SWITCH
DASHBOARD LOOM 12 WIRE CONNECTOR BLOCK x 2 VARIOUS PRE-WIRED
EARTH FOR RESISTOR CIRCUIT
ON MASTER SWITCH
1 FEMALE SPADE CONNECTOR BLACK SEE MASTER SWITCH INSTALLATION SECTION
MAIN EARTH LEAD RING TERMINAL 5 BLACK CONNECTS TO CHASSIS
