Westfield XTR2 - Page 39

4.12
LOOM MID SECTION
FUEL TANK SENDER 2 FEMALE SPADE CONNECTORS BLACK ; GREEN / BLACK ORIENTATION UNIMPORTANT
PRIMARY FUEL PUMP 1 FEMALE SPADE CONNECTOR GREEN PRE-WIRED TO PUMP MOUNTED ON CHASSIS SIDE
EARTH TO HIGH PRESSURE
FUEL PUMP
1 FEMALE SPADE CONNECTOR BLACK PRE-WIRED TO PUMP MOUNTED ON CHASSIS FLOOR
COOLING FAN SWITCH CONNECTOR BLOCK (BLUE) GREEN ; BLACK PRE-WIRED
COOLING FAN MOTOR CONNECTOR BLOCK (WHITE) 2 BLACK PRE-WIRED
ENGINE LOOM CONNECTOR BLOCK ORANGE, GREEN ; WHITE / BLACK ;
WHITE / RED
PRE-WIRED
REVERSE SOLONOID 2 FEMALE SPADE CONNECTORS ORANGE, BLACK / GREEN ; TO SPADE TERMINALS ON SOLONOID, ORIENTATION
UNIMPORTANT.
LOOM REAR SECTION
OFFSIDE REAR LIGHT CLUSTER 3 TERMINAL CONNECTOR BLOCK
2 TERMINAL CONNECTOR BLOCK
BLACK – 1 PAIR
GREEN / PURPLE
RED / ORANGE
BLACK ; GREEN / WHITE
BRAKE & SIDE LIGHT
INDICATOR (DRIVER SIDE)
NEAR SIDE REAR LIGHT
CLUSTER
3 TERMINAL CONNECTOR BLOCK
2 TERMINAL CONNECTOR BLOCK
BLACK – 1 PAIR
GREEN / PURPLE – 1 PAIR
RED / BLACK
BLACK ; GREEN / RED
BRAKE & SIDE LIGHT
INDICATOR (PASSENGER SIDE)
FOG LIGHT 2 PIN CONNECTOR BLOCK BLACK ; RED / BLUE
NUMBER PLATE LIGHT BARE WIRES BLACK ; RED / BLACK CUSTOMER TO FIT BULLET CONNECTORS SUPPLIED
