5.4
Step 2: Fit Pedals
View From Drivers Seat Area
Step 3: Fit Pedal Push Rods
Clutch Pedal
Brake Pedal
NOTE
T
he Brake Pedal Is Shown
With An Adjustable Bias-Bar
Fitted. The Non-Adjustable
Bias-Bar MUST Be Fitted
Initially To Pass The SV
A
Test.
A
ccelerator Pedal
M8 x 220mm long
Zinc Plated Stud
M6 Bolt x 20 Long
M6 Plain Nut
Lubricate The Steel Spacer
Bushes with `Copper Slip
Before Inserting Into The
A
ssembly.
Y
ou MUST Ensure All Pedals
Move Freely After Tightening
The Nyloc Nuts.
Cut Head Of
f
2x5/16” UNF
Bolts & Fit 2
Lock Nuts
Brake Pedal
Push Rods
Lock Nut
Rubber
Gaitors
Brake Pedal
NOTE
Clutch Pedal
Push Rod
Clevis Pin And
Split Pin
Clevis Fixed
with 5/16” Bolt
and Lock Nut
T
he Brake Pedal Is Shown
With An Adjustable Bias-Bar
Fitted. The Non-Adjustable
Bias-Bar MUST Be Fitted
Initially To Pass The SV
A
Test.
S
p
acer 25mm Lon
g
S
p
acer 55mm Lon
g
View From Above
