13.5
Step 3: Install Sprocket
View From Rear Of Car
Note; When The Engine And Differential With Chain Fitted Are Lined Up
Correctly The 4 Grub Screws In The Two Main Differential Bearing Carriers
Need To Be Locked Up Tightly.
Use M10 x 30 Bolts and Nyloc
Nuts Provided.
NOTE: On the Internal Diameter
of The Sprocket on One Side Only
There Is A Chamfer. This Must Go
up To The Flange Face On The
Diff.
