Wfly ET07 - Link Step

32
The link function is used for matching the
transmitter and receiver.
Warning:When linking, please be careful not to
connect the power equipment, and remove the
propeller, pay attention to safety!
To ensure safety, please do not link in the
status where the motor and engine are running.
Note:
1. The transmitter and receiver must be close to
each other (less than 1 meter);
2. The transmitter cannot perform link operation
in the simulator and student mode ([System Setting]
→ [Trainer] to set);
3. There is no other WFLY 2.4GHz system in
progress.
4. In the process of linking, if you need to exit the
link, click the "Cancel" button or press the Back
button.
5. After finished the link, the connection
verification must be performed.
6. Telemetry: Disabling this function when link will
affect the use of [Range check] [Low battery] [BUS
Servo Setting] [Telemetry],etc.
Receiver
Power on
Press and hold SET
for 3 seconds
Boot
Start Link
Transmitter
Transmitter
Receiver
Output Slot
Preset channel
Model A
Model B
1
1
5
2
2
6
3
3
3
4
4
7
5
5
8
6
6
9
7
7
10
8
W.BUS/PPM
W.BUS/PPM
W.BUS2
W.BUS2
W.BUS2
Link Step
Linkage Setting
Interface path: →Linkage Setting→Link WFLY
Setting method:
1. After the receiver enters the link status (the
receiver is powered on, press and hold the SET
button for 3 seconds, the orange light flashes
slowly);
2. Transmitter, click the "Start" button to enter the
link status (RF light flashes slowly);
3. After link successfully, the transmitter RF light
is always on, the receiver green light is always on
(default W.BUS mode), or the blue light is always on
(PPM mode).
Verification: connect the servo, operate the
transmitter, and the corresponding servo has the
synchronous action output, that is link successful;
The selection of the working mode (default
working mode A) uses the default value when using
channels with less than seven channels. When
using more than seven channels (using two
receivers), refer to the following list for link setting.
RX
NOR M
4.2 V
Link
INH
Mode A
Telemetry
Mode
Link Start
00: 0 6: 59
*Receiver firmary：V1.1.04
DANGER
