Model Ci User Manual
5. Assembly, Adjustment, and Disassembly
5.4.4. Removing the front drive base
1. Pull the base release lever toward you to
release lock between the front drive base and
rear drive base.
2. Grasp handle A and disengage handle B
from the hook of the rear drive base.
Support the rear drive base with a hand while
disconnecting so that the rear drive base does
not fall over.
3. Place the disassembled front drive base and
rear drive base as shown in the photo at
right.
Base
release
lever
Handle A
