5.4.1. Removing the battery
1. Check that the device power is off.
2. Insert the key into the keyhole at the top of
the battery and turn the key to unlock the
battery.
3. Grasp the handle and pull it toward you to
remove the battery.
Pull the handle toward you and lift up the
battery to disconnect it from the projections at
the bottom.
The battery weighs 6.2 lbs ( 2.8 kg) . Be careful
not to drop it when removing it. There is a risk
of injury or damage caused by the battery
dropping.
Keyhole
Projections
