3.2.2. Charging with the battery removed
1. Check that the device power is off.
2. Insert the key into the keyhole at the top of
the battery and turn the key to unlock the
battery.
3. Grasp the handle and pull it towards you to
remove the battery.
The battery weighs 6.2 lbs (2.8 kg). Be careful
not to drop it when removing it. There is a risk
of injury and of damage to the battery.
4. Connect the charger and AC connector cord.
Keyhole
Projections
To Next Page
