Other labels
The following is an explanation other labels used on this device.
Symbol Label Meaning
H
Indicates the brake release levers lock position and unlock
position.
I
Indicates the arm length adjustment position. The arm length can
be adjusted in 4 stages.
J
Indicates the procedure for disconnecting the connectors from
the directional controller assembly and control pad.
K
Indicates the battery removal key lock position and unlock
position.
L
3
4
5
Indicates the device disassembly procedure.
M
Indicates the seat assembly insertion position when installing the
seat assembly onto the rear drive base.
N
Indicates the procedure for adjusting the back support angle (90°,
95°, or 100°).
O
Indicates the reference point that is checked when the back
support angle is adjusted.
P
Indicates the back support angle adjustment positions (90°, 95°,
100°).
