1. Remove the battery.
For the removal procedure, refer to “5.4.1
Removing the battery”.
2. Remove the seat assembly.
For the removal procedure, refer to “5.4.2
Removing the seat assembly”.
3. Use a hex wrench (#8) and remove the seat
post bolt.
4. Move the seat post up or down and align
with the hole that you want to adjust it to.
The seat height can be adjusted in 5 stages.
There is a cable inside the seat post. Pulling
forcefully on the seat post may pull and break
the cable inside it.
Be careful not to forcefully pull on the seat
post.
Bolt
Seat post
Cable
To Next Page
